Single speed pneumatic torque wrench

High output and repeat accuracy: ±5% and ±3%
Air pressure requirements: no less than 6 bar
Air flow requirement: 600L/min ~1000 L/min.
Powerful and low noise, less than 80Dba under max.power
Set and control torque by adjusting the pressure, convenient and high repeatability
With single speed gearbox, light weight,small size and high speed, easily operated
Very suitable for continuous operation in production assembly and maintenance
Reverse pressure-bias motor provide the higher power and torque when removing or loosening bolts
Free connection of power handle and drive unit, could be rotated 360°.
After-sales service: 1 year guarantee period, then lifelong maintanence.
  • KSPW

  • KASHON

Availability:
Quantity:
sharethis sharing button

HTB1BUo.PVXXXXaUXFXX760XFXXXj

Model

Min torque

(N.m)

Max torque

(N.m)

Square drive

S

(mm)

Outside diameter

D(mm)

Length  M

(mm)

Length  L

(mm)

Width   K

(mm)

Weight

(Kg)

Max speed

rpm

KSPW-09SS

290

950

3/4"

74

172

302

195

5.4

20.5

KSPW-16SS

480

1640

1"

78

214

344

195

6.9

11.5

KSPW-20SS

490

2050

1"

78

214

344

195

6.9

9.0

KSPW-30SS

810

3100

1"

88

254

384

195

9.7

5.5

KSPW-40SS

1190

4300

11/2"

88

254

384

195

9.7

3.8

KSPW-60SS

1100

6200

11/2"

113

283

413

195

15.1

2.7

KSPW-80SS

1600

8000

11/2"

120

292

422

195

16.8

1.9

KSPW-100SS

3700

10600

11/2"

128

336

466

195

21.6

1.4

KSPW-120SS

3900

13500

11/2"

128

336

466

195

21.6

1.1
